ODC connector is next generation connectors for wireless base station application (WCDMA/TD-SCDMA/CDMA200/Wi-MAX/GSM) that can meet the requirements of FTTA (fiber to the top of the tower). We developed ODC connectors base on special connectors craft, our ODC connector’s interface can be compatible with the mainstream of the current global supplier of ODC connector.
The ODC Cable assemblies have passed testes like salt mist, vibration and shock and meet protection class IP67. They are well suited for Industrial and Aerospace and Defense applications
Feature:
1.2fibers,4fibers,singlemode or multimode
2.Compact design with 2×1.25mm ferrules
3.Built-in socket with square or hexagonal flange
4.Extension connector for cable chaining
5.Screwed locking mechanism
6.Easy and safe installation
7.Water proof,dust proof and corrosion resistant
8.Water proof protection caps
9.EMI protected
10.RoHs compliant
11.Fulfills performance standard IEC 61753-1 Cat.E
Application
FTTX /FTTASystems
PON Networks
CATV Links
Optical Signal Distribution
Basic SPEC Information:
